The PTZOptics SuperJoy
Available Now
Network and Serial Joystick Camera Controller
SuperJoy
Tech Specs
Firmware Updates
Documentation
Videos
Create a Powerful, Precise and Versatile Production Experience
Introducing the PTZOptics SuperJoy, a PTZ camera joystick controller designed for smooth, efficient production workflows. The SuperJoy takes remote pan, tilt, and zoom camera operations to the next level in a simplified user interface with advanced controls for power users.
Streamlined, Real-Time Production
The SuperJoy offers an intuitive, tactile interface, simplifying and streamlining even the most complex production setups.
- SuperJoy’s HDMI video output provides a 1080p video preview for any camera connected to the SuperJoy that has an RTSP video feed available for use. This HDMI video output is ideal for viewing cameras over a local area network. In this way, a SuperJoy controller can be set up anywhere on a network to gain PTZ camera controls with a low-latency, live video preview.
- Ergonomic, rubberized controls and pressure-sensitive dials for precise, on-the-fly-tuning, with no OSD adjustments required
- Status-responsive backlit buttons and knobs indicate available camera modes, while optional tablet/computer control can allow for remote monitoring
Custom Control Across a Variety of Cameras and Devices
The PTZOptics SuperJoy Joystick Controller is a comprehensive solution supporting mix-and-match serial and network-based control for PTZ cameras of any generation.
- Simultaneous pan, tilt and zoom control across IP, NDI® and serial cameras from multiple brands including PTZOptics, HuddleCamHD, Sony, BirdDog, Lumens, Marshall, NewTek, and Panasonic (newer Panasonic cameras that support Sony VISCA will work).
- If it’s IP-controlled, chances are the SuperJoy can control it – cameras, lights, projector screens and more – using four customizable buttons.
- Powerful Super-Preset buttons are programmable to trigger synchronized multi-preset commands across up to four unique camera groups with up to seven cameras each, as well as a fifth group of up to 225 cameras.
From Power Users to Novices, a Controller for Everyone
With three user-centered control modes designed to accommodate varying skill levels, the SuperJoy offers unparalleled flexibility for production teams of all backgrounds and experiences.
- Use Basic and Basic Plus mode to limit functions to presets and single-camera control
- Matrix mode enables operators to call presets across up to three cameras
- Expert users can program custom buttons for production automation
New Custom Button
Take a new level of control over your production with a customizable joystick button. This button is conveniently located at the top of the joystick controller for quick access to your most used functions. This joystick button is fully customizable so you can choose if you want it to start recording in your video production software OR start auto-tracking on your currently selected camera.
Automatic Triggers
PTZOptics IP joystick controllers now support automatic triggers which can be used to trigger a command when switching a camera. Automatic Triggers are ideal for integrating your PT-JOY-G4 or PT-SUPERJOY-G1 joystick controllers with your video switcher or other production equipment. Use Automatic Triggers to automate your video production workflow to effortlessly queue up your next camera or prepare your next scene.
Unrivaled Warranties
With robust warranties included standard on every product, you can trust PTZOptics solutions to deliver high performance from day one, and for many years to follow.
The SuperJoy comes with a 2-year limited parts and labor warranty. PTZOptics stands by our promise to protect your investment by providing repairs or replacement products for the duration of your warranty. For more information, view our complete warranty documentation for products purchased in the United States here. View our warranty documentation for products purchased internationally here.
PTZOptics Continuous Advantage
PTZOptics products continuously improve over their lifespan. Since 2014, PTZOptics has provided customers with regular, free product updates based on customer feedback, enhancing the value and functionality of their products over time. For example, the PTZOptics award-winning second generation camera line was improved with over 100 new features over its 7-year production life-span. Beginning in 2023, updates can be applied with a single click. Additionally, our new PTZOptics Discord channel allows users to communicate directly with our engineering team and access beta firmware. This approach enables products to evolve with users’ needs, increasing their overall value. Learn about our beta tester program here.
Unparalleled Value, Award-Winning Support
When you reach out to PTZOptics for support, you won’t get an automated system — you’ll get a team of in-house, US-based experts ready to help. Connect with us via:
- Phone, email, and chat
- Our detailed knowledge base and forum
- Our online Udemy course
- Our support ticket system
- Our Facebook user group
- Our weekly live shows
Features and
benefits
- Simultaneous NDI®, IP & Serial Control for a Range of PTZ Cameras
- Create 5 Camera Control Groups (Cam Groups 1-4: 7 channels, Cam Group 5: 225 channels)
- Multi-Brand Compatibility, including Sony, BirdDog, NewTek & More
- Large LCD Screen with Controller Status and built-in decoder with HDMI output
- Basic, Basic Plus & Matrix Modes for Users of All Skill Levels
- Up to 255 PTZ Camera Presets, 9 Quick Presets, and 4 Super-Presets
Future Proof Your Technology
Joystick Comparison
HC-JOY-G4
329
- Cabling: RS-232, RS-485, RS-422
- Max Cable Distance: 3,937’ (1200m) using 24 gauge twisted pair (for RS-485 only)
- Power: DC12V
- Control Protocol: VISCA, PELCO-D, PELCO-P
- Maximum Cameras: 255 cameras
- Design Notes: Works with any PELCO camera
- USB
PT Joystick G4
714
- Cabling: RS-232, RS-485, RS-422, RJ-45
- Max Cable Distance: 3,937’ (1200m) using 24 gauge twisted pair (for RS-485 only)
- Power: 6W|12VDC/PoE (802.3af) (Only use one power source at a time)
- Control Protocols: VISCA over IP (PTZOptics & Sony) or Serial Control (RS-232, RS-485, Pelco-D, & Pelco-P)
- Multiple Control Types: IP OR Serial (must manually toggle between the two)
- Maximum Cameras: 255 cameras via network, 7 cameras via serial VISCA
- Design Notes: Compatible with most PTZ cameras
- USB (only for firmware upgrades)
- HDMI Output
SuperJoy
989
- Cabling: RS-232, RS-485, RS-422, RJ-45
- Max Cable Distance: 3,937’ (1200m) using 24 gauge twisted pair (for RS-485 only)
- Power: 6W|12VDC/PoE (802.3af) (Only use one power source at a time)
- Control Protocols: VISCA over IP (PTZOptics & Sony), Serial Control (RS-232, RS-485, Pelco-D, & Pelco-P), & NDI®
- Multiple Control Types: IP AND Serial
- Maximum Cameras: 255 total cameras (28 cameras (4 groups of 7 channels) plus a group with up to 227 cameras)
- Design Notes: Compatible with most PTZ cameras
- USB (only for firmware upgrades)
- HDMI Output
Where to Buy
Ready to get started? Just fill out the form below and we’ll be in touch shortly.
Proudly Partnering With:
See What Our Customers Are Saying
Superior Performance, Flexibility and Support – All for Less Than You Might Think
Backed by PTZOptics’ 2-year warranty, plus full support from PTZOptics’ technical team, the SuperJoy is an ideal choice for video production crews looking to improve their workflows and streamline their production processes.
And starting at only $899, a better production experience is more accessible than ever.
Unlock the Power Network Control
Take full control of your robotic PTZ camera with these resources…
- VISCA: Serial connections include PTZ cameras with RS-232 and RS-485 from brands such as Aver, AIDA, BirdDog, Bolin, ClearOne, DataVideo, JVC, Lumens, Marshall Electronics, RGBLink, SONY
- SONY VISCA over IP: Includes PTZ cameras from AIDA, AVer, BirdDog, Bolin, BZBGear, ClearOne, JVC, Lumens, SONY
- PTZOptics VISCA: All PTZOptics cameras, HuddleCamHD
- NDI®: Includes NDI® PTZ cameras from AIDA, AVer, BirdDog, Bolin, BZBGear, Canon, ClearOne, DataVideo, HuddleCamHD, JVC, Lumens, Marshall Electronics, NewTek, Panasonic, RGBLink
- PELCO-P and PELCO-D: Includes PTZ cameras from BirdDog, DataVideo, JVC, Lumens, RGBLink, Marshall Electronics
- Panasonic (HTTP): Panasonic Cameras
*These brands support industry standard protocols. Please check individual camera models to ensure compatibility with the standards supported by our joystick controllers.
| Technical Specifications | Connections | RS-232, RS-485, RS-422, RJ-45 |
| Control Protocols | VISCA, VISCA over IP, PELCO-D, PELCO-P, Sony, & NDI® | |
| Max Cameras | 28 cameras total (5 groups of 7 channels) | |
| Recommended Max Distance | RS-232 / RS-422: 50 ft | 15m RS-485: 3,937 ft | 1200m Ethernet: 328 ft | 100m | |
| Baud rate | 1200 -19200 bps | |
| Operation Specifications | Power | 6W112VDC / PoE (802.3af) (Only use one (1) power source at a time.) |
| Working Temp | 14° F -122° F | -10° C +50°C | |
| Working Humidity | 10% ~ 90% (non-condensation) | |
| Weight | 3.75 lbs | 1.70 kg | |
| Dimensions (in.) | 13.94 W x 7.05 D x 3.98 H | |
| Dimensions (mm.) | 370 W x 180 D x 101 H |
Latest Firmware Features for the SuperJoy
11/16/2023 New Firmware Feature Highlights:
- New Custom Button
Take a new level of control over your production with a customizable joystick button on the PT-JOY-G4 and PT-SUPERJOY-G1 controllers. This button is conveniently located at the top of the joystick controller for quick access to your most used functions. This joystick button is fully customizable, so you can choose if you want it to start recording in your video production software, instantly start auto-tracking on your currently selected camera, dim the lights, and so much more!
- SuperPresets
The PT-JOY-G4 can now trigger SuperPresets to control up to eight cameras with a single click. SuperPreset buttons can trigger synchronized PTZ preset commands across the selected cameras and a custom HTTP trigger for automation with video production software. The PT-SUPERJOY-G1 was the first PTZ joystick to offer this feature, and the PTZOptics engineering team is happy to announce this functionality is now available in our more affordable PT-JOY-G4 model.
- Automatic Triggers
PTZOptics IP joystick controllers now support automatic triggers, which can be used to trigger a command when switching a camera. Automatic Triggers are ideal for integrating your PT-JOY-G4 or PT-SUPERJOY-G1 joystick controllers with your video switcher or other production equipment. Use Automatic Triggers to automate your video production workflow to effortlessly queue up your next camera or prepare your next scene.
- New Dynamic Camera Variable
There is a new variable that can be used in the SuperJoy’s and the PT-JOY-G4’s Web UI to optimize the use of custom buttons. Using the new {{CURRENT_CAM}} stub instead of a hard-coded IP address allows you to send a custom command to the currently selected camera. This new option allows you to use custom button commands with a vastly larger amount of cameras.
- Panasonic PTZ Camera Controls
PTZOptics IP joystick controllers now support Panasonic PTZ cameras via the Panasonic HTTP Commands. When setting up a PTZOptics joystick controller with a Panasonic PTZ camera, you must know the camera’s unique IP address. When adding a Panasonic camera to the joystick controller, select “Panasonic” as the control protocol. It’s easy to control Panasonic network-connected PTZ cameras to PTZOptics IP joystick controllers.
- Additional Feature Updates and Bug Fixes
Additional features and bug fixes are outlined in the firmware changelog for each joystick here. Other notable features include the ability to save Pan, Tilt, Zoom, and Focus speeds for each camera, along with the ability to display Exposure and White Balance on the LCD screen of the SuperJoy. If you have feature requests for your IP joystick controller, our team would love to hear about them. Share your experience as a PTZ camera operator in our Facebook User Group here.
The full firmware changelog is available in the Web UI. Questions? Contact support at community.ptzoptics.com.
Download the Latest Firmware Below!
| SKU | Zip File |
|---|---|
| PT-SUPERJOY-G1 | Download Now |
